PE Film Blow machinery with Rotary-die Head and Double Winder
- LD
1 Piece PE Film Blow machinery with Rotary-die Head and Double Winder
- Shandong, China
- CE,ISO
- 1set
- US$1000.00-USD800,000.00
- standard package
- T/T,Western Union
- 30 Set/Sets per Month
-
Potato chip production line2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Details
| Condition: | New | Application: | Film | Plastic Processed: | PE |
| Blow Moulding Type: | FILM BLOWING | Automatic: | Yes | Place of Origin: | Jinan, China (Mainland) |
| Brand Name: | LD | Model Number: | SJ-65 | Voltage: | 380V |
| Power(W): | 18.5kw | Dimension(L*W*H): | 5500mm*2500mm*4500mm | Weight: | 3000KG |
| Certification: | CE | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service overseas |
| Color: | Blue and white | Material: | HLDE LLDE LLLDE | Capacity: | 65kg/h |
| film width: | 1200mm |
Product Description
Model |
SJ-55 |
SJ-65 |
SJ-75 |
|
|
Features |
Raw Material |
HLDE, LLDE, LLLDE; Virgin and Recycled |
||
Film data-width |
800mm |
1200mm |
1500mm |
|
Average Output |
50Kgs |
65Kgs |
85Kgs |
|
|
|
|
|
|
Film Thickness |
0.008mm-0.15mm |
|||
Power supply |
380V, 3Phase, 50Hz |
|||
Weight |
2000kgs |
2600kgs |
3000kgs |
|
Dimension |
||||
Extrusion Unit |
Screw&Barrel Diameter |
55mm |
65mm |
75mm |
Screw&Barrel L/D ratio |
28:1; or 30:1 |
|||
Motor |
15KW |
22KW |
37KW |
|
Gearbox |
146 |
173 |
200 |
|
Die Head LLDe |
Rotary Die Head |
|||
Die Size |
50/80 |
60/100 |
120/160 |
|
Heating |
11KW |
11KW |
13KW |
|
Blower |
3KW |
|||
|
Film |
Upper Tower LLDe |
Rise and Fall |
||
Roller Length |
900mm |
1350mm |
1700mm |
|
Roller worldWay |
Opened and Tightened By Air Cylinders |
|||
Take Up Motor |
1.5KW |
|||
Winding Station |
Winder LLDe |
Double winding station |
||
Rollers |
900mm |
1350mm |
1700mm |
|
Torque Motor |
15N/M |
|||
Max. Winding Diameter |
600mm |
|||
Control Panel |
Temperature control |
5 zone |
||
Electronics |
Top China Brand |
|||
Inverter Capacity |
15KW/1.5KW |
22KW/1.5KW |
37KW/1.5KW |
|
Optional Equipment |
